Product Description

High-pressure Multistage Centrifugal Blowers - Powerful Pressure Output for Industrial and Large Pipework Systems

Key Features:

1. High-Pressure Performance:

   • Multistage centrifugal design delivers exceptional pressure output up to 100 kPa
   • Ideal for applications requiring substantial pressure differentials

2. Industrial-Grade Durability:

   • Robust construction using heavy-duty materials
   • Engineered to withstand harsh operating conditions

3. Large Volume Airflow:

   • High volumetric flow rates up to 50,000 m³/h
   • Capable of meeting the ventilation demands of sizeable industrial facilities

4. Energy-Efficient Operation:

   • Optimized aerodynamic design minimizes power consumption
   • Reduced operating costs through superior energy efficiency

5. Versatile Configuration:

   • Available in single-stage or multi-stage configurations
   • Customizable to suit diverse industrial applications

Product Features

The shell of inlet and outlet, and retum channel of blower are fully adapt to impeller, The streamline design reduces loss

The impeller is designed by three-dimensional meridian plane and compound curve technology,enjoys high efficiency.

The impeller intake seal-inducer improves inlet fluidity of impeller.
The airfoil return-flow blade can reduces loss ,gets high static pressure.

The blower perfomance was optimized with fluid analysis technology, The polytropic efficiency is up to 78%

Some blowers use Three-dimensional impeller, which have high efficiency and good performance.

After strict dynamic balance, the rotor has low vibration, high reliability and low overall noise.
The structure of blower is advanced and reasonable .Easy-worn parts are few, installation, operation and maintenance areconvenient.

Stator



The stator is vertical split type structure, which is consists of the inlet chamber.intermediate casing and discharge scroll case, these parts make up of the gas channels withbolts. The inlet chamber, intermediate casing and discharge scroll case are founded usinghigh quality castiron and rosin model, having small distortion after strict anneal dispose.Stator with high precision and high coaxial can insure stable operation of rotor assembly



Rotor



Rotor is consists of impellers, main shaft, shaft sleeve, half coupling and soon. The main shaft makes use of the high quality carbon-steel, and carries throughquenching and tempering.After assembly, the rotor was dynamically balanced toensure steady and reliable running.

Scope of application



It is suitable for sewage treatment industry, petrochemical industry, food and drug industry, textile industry, metallurgy industry, cement and construction materials industry, printing and dyeing industry and other industries.





specification

Notice: 1, When the atmospheric conditions and medium are varied, the relative performance conversion calculation will be different.We can re-designed in accordance with the requirement of users to adapt to diferent working condition.
2. When transporting non air medium, our company carries on the corresponding antiseptic treatment to the inside of the shell and the impeller, so as to satisfy the customer's demand.
3. " "are 6kV high-voltage motor, others are motors with voltage 380V.

Market Distribution





We have 42 offices throughout the country, in addition to Taiwan Province, 33 provinces in the country's ad-ministrative regions have a sound sales and service network. We can provide you with pre-sale, in-sale and after-sales service in a timely and convenient manner, understand your needs, and constantly improve the service and quality system while meeting the customized needs of customers.





High Performance Aerodynamic Design Methodology for Wide Service Conditions



By studying the influence of impeller and volute flow on efficiency and working stability, the R&D team proposed a flow control method and a pneumatic optimization design method to improve the performance of the main engine, which greatly improved the efficiency of the main engine.



Manufacturing & Equipment Base



has built laboratories, R& D buildings, processing workshops, etc., with internationally advanced and China leading high-precision processing equipment.
