Product Description:
Foil Bearing High-speed Centrifugal Blowers is a high-effi- ciency, energy-saving, green and environmentally friendly product, its mechanical structure is simple, the moving parts are few, the control robustness is good, and the maintenance is convenient. It adopts automotive-grade oil-free and high-reliability dynamic pressure foil bearing, which has no friction and small mechanical loss during operation. Using advanced permanent magnet synchronous motor technology, the maximum speed can reach 95000rpm, and it only takes 5s to run at full speed. The motor efficiency is as high as 97%, which meets the two-stage energy efficiency standard.
Features:
1. Core Technology: Air Suspension Bearing
Contactless suspension: The impeller and bearing system designed with aerodynamics ensures that the rotor and bearings have no physical contact during operation, eliminating mechanical friction and achieving zero wear.
High precision control: Real time adjustment of bearing film thickness through intelligent control system ensures stable operation and minimal vibration (usually ≤ 1mm/s).
No lubrication required: eliminates the need for a lubricating oil system for traditional blowers, avoids oil pollution, and reduces maintenance costs.
2. High efficiency and energy-saving features
Permanent magnet synchronous motor: Paired with an efficient permanent magnet motor, the efficiency can reach over 95%, saving 30% to 50% energy compared to traditional Roots blowers.
Variable frequency speed regulation: Automatically adjust the speed according to the working conditions (usually within the range of 20000~50000 RPM) to achieve precise air volume/pressure control and avoid energy waste.
Low noise design: The operating noise is usually below 80dB (A), suitable for noise sensitive environments.
3. Intelligent control system
PLC/touch screen integration: Real time monitoring of parameters such as wind pressure, flow rate, temperature, and speed, supporting remote operation and fault diagnosis.
Automatic protection function: equipped with overload, overheating, and surge protection to ensure safe operation of the equipment.
IoT compatibility: Some models support cloud data access for intelligent management.
4. Product advantages
Long lifespan: No mechanical wear and tear, designed for a lifespan of over 15 years.
Maintenance free: eliminates the need for regular maintenance work such as changing lubricating oil and belts, and only requires regular replacement of the air filter.
Compact structure: The volume is 30%~50% smaller than traditional blowers, saving installation space.
Environmental compliance: No oil emissions, compliant with ISO 8573-1 Class 0 oil-free standard.
Technical Parameters:
When the atmospheric conditions and medium are varied,the relative performance conversion calculaltion will be different,we can re-designed in accordance wth the requirement of users to adape to different working condition. There are two cooling methods for air suspension centrifugal blower: self-circulating water cooling and forced air cooling, If you have special requirements on the cooling mode, please tell us in advance.
Applications:
- 1. Sewage treatment industry (core application)
Aeration oxygen supply:
Used in activated sludge processes (such as AAO, SBR, oxidation ditch, etc.) to provide oxygen to microorganisms and promote organic matter degradation.
Energy saving advantages: Compared to traditional Roots blowers, it saves 30% to 50% energy and significantly reduces the electricity consumption cost of sewage treatment plants.
Case: Municipal sewage treatment plant, industrial wastewater treatment (chemical, printing and dyeing, papermaking, etc.).
Provide a stable gas source for the dissolved air flotation (DAF) process to separate suspended solids in water.
- 2. Chemical and pharmaceutical industries
Pneumatic conveying:
Transporting powdered and granular raw materials (such as PVC powder, catalysts, etc.), ensuring material purity without oil pollution.
Fermentation gas supply:
Provide sterile compressed air for biological fermentation tanks (such as antibiotic and enzyme production) to avoid lubricant contamination.
Reaction kettle stirring:
Replace mechanical mixing to reduce the risk of seal leakage.
- 3. Electric power and metallurgical industry
Flue gas desulfurization (FGD):
Provide oxidizing air for the desulfurization tower to promote the conversion of calcium sulfite to calcium sulfate.
Blast furnace oxygen enriched blowing:
Improve combustion efficiency and reduce coke consumption.
Cooling system:
Used for circulating cooling towers or equipment heat dissipation.
- 4. Food and beverage industry
Clean compressed air:
Meets ISO 8573-1 Class 0 oil-free standard, used for packaging, filling, fermentation and other processes.
Pneumatic conveying:
- 5. Textile and electronics industry
Loom gas supply:
Provide stable airflow for jet looms, replace traditional screw fans, and reduce energy consumption.
Electronic Cleanroom:
Provide dust-free and oil-free compressed air for controlling the production environment of chips and LCD panels.
Transport food ingredients such as flour and sugar powder to avoid the risk of oil contamination.
- 6. Other emerging applications
Garbage incineration power generation:
Combustion air supply to improve combustion efficiency.
Aquaculture:
Aerobic aeration enhances water solubility and is suitable for high-density aquaculture ponds.
New energy batteries:
The drying process in lithium battery production provides oil-free hot air.
Customization:
Brand Name: Aipu
Place of Origin: China
Certification: CE,CCC,SABS,TUV,RoHS
Price: Negotiable
Packaging Details: Standard Export Package
Delivery Time: 6-8 workdays
Type: Universal Fit
Flow Rate: 1.03 CFM
Amperage: 15A
Outlet Size: 1/4 Inch
Warranty: 2 Years
Our Air Suspension Blowers, also known as Air Cushion Machine Blowers, Bouncy Castle Air Blowers, and Bouncy Castle Air Blowers, can be customized to meet your needs and preferences. Contact us for more information on how we can customize our product to fit your specific requirements.
Support and Services:
The Air Suspension Blowers product provides technical support and services to ensure customer satisfaction. Our team of experts is available to assist with any questions or concerns regarding the installation, maintenance, or performance of the product. Additionally, we offer repair and replacement services for any defective or damaged parts. Our goal is to provide reliable and efficient air suspension solutions to our customers.
Packing and Shipping:
Product Packaging:
The Air Suspension Blowers product will be securely packaged in a durable cardboard box to ensure safe delivery. The product will be wrapped in protective materials and include a user manual and any necessary accessories.
Shipping:
The product will be shipped via standard ground shipping and will be delivered within 3-5 business days. Expedited shipping options are also available at an additional cost. The customer will receive a tracking number once the product has shipped to track their order.
FAQ:
Here are some frequently asked questions about Aipu air suspension blowers:
Q: What is the brand name of this air suspension blower?
A: The brand name of this air suspension blower is Aipu.
Q: Where is this air suspension blower made?
A: This air suspension blower is made in China.
Q: What certifications does this air suspension blower have?
A: This air suspension blower has CE, CCC, SABS, TUV, and RoHS certifications.
Q: What is the price of this air suspension blower?
A: The price of this air suspension blower is negotiable.
Q: What are the packaging details for this air suspension blower?
A: The packaging details for this air suspension blower are standard export package.
Q: How long will it take to receive this air suspension blower?
A: The delivery time for this air suspension blower is 6-8 workdays.
